prism
Rhino plugin · v0.3.1.1 · updated
Prism is a Plug-in for Rhino that sorts geometric objects into layers based on their properties and attributes (names, colors, user-texts etc.) Prism is particularly useful when importing data from „attribute-based“ CAD applications (e.g. Cadwork) to the „layer-based“ Rhino. Typically, the imported geometry keeps their attributes as user-texts, but ends up on just one layer.
Install in Rhino
Install from the computer that runs Rhino · How to install
Download .yakWebsite (opens in a new tab)- Total downloads
- 84~0.3/day
- This week
- +11+21 this month
- Releases
- 1
- First released
- Dec 23, 2025
- Works with
- Rhino 8 · Windows & Mac
- Download size
- 2.8 MB
- License
- Not declared
- Credits
- Design-to-Production
How to install prism
- Click Install in Rhino to open Rhino's Package Manager with prism selected, or run
_PackageManagerinside Rhino and search for prism.On the computer running Rhino, run_PackageManagerand search for prism. - Or install it from a terminal (assumes a default Rhino 8 installation):Windows (PowerShell)
& "C:\Program Files\Rhino 8\System\Yak.exe" install prismmacOS (Terminal)"/Applications/Rhino 8.app/Contents/Resources/bin/yak" install prism - Or download a .yak file and drag it onto an open Rhino window.
- prism-0.3.1.1-rh8_0-any.yakWindows & Mac · Rhino 8.0
Restart Rhino once the install finishes.
Download trend
prism version history
| Date | Version | Builds | Downloads | Install |
|---|---|---|---|---|
| Dec 23, 2025 | 0.3.1.1 | 84 | Install |
