Rhino Packages

pillbug

Rhino plugin · v1.0.0-pre2 · updated

Pre-release

rhino sheet metal unfolder. takes a closed polysurface, picks the up-face, produces a 2D flat pattern on classified fabrication sublayers (Outside cut, Inside cut, Mark) ready for direct DXF export to CNC. bend angle text with UP / DN convention. preserves through-holes that cross bend lines. paid product distributed via dfma.tools; license file required.

Install in RhinoDownload .yakWebsite (opens in a new tab)Open in directory
Total downloads
13
Recent downloads
+1 / week+6 in the last month
Latest version
v1.0.0-pre25/28/2026
Releases
2every ~1.0d
First released
5/27/2026
Download size
453 KB
License
Not declared
Authors
Travis Walters

Compatibility

Supported: WindowsSupported: MacNot supported: Rhino 6Not supported: Rhino 7Supported: Rhino 8Not supported: Rhino 9 (WIP)Supported: Rhino pluginNot supported: Grasshopper plugin
Keywords: cncdxffabricationflat-patternrhinosheet-metalunfold

How to install pillbug

  1. Click Install in Rhino to open Rhino's Package Manager with pillbug selected, or run _PackageManager inside Rhino and search for pillbug.
  2. Or install it from a terminal (assumes a default Rhino 8 installation):
    Windows (PowerShell)
    & "C:\Program Files\Rhino 8\System\Yak.exe" install pillbug
    macOS (Terminal)
    "/Applications/Rhino 8.app/Contents/Resources/bin/yak" install pillbug
  3. Or download the .yak file above and drag it onto an open Rhino window.

Restart Rhino once the install finishes.

Download trend

9 downloads on 2026-07-13 → 13 on 2026-10-07

pillbug version history

DateVersionBuildsDownloads
5/28/20261.0.0-pre2Pre-release10
5/27/20261.0.0-pre1Pre-release3
